Concrete Pump Hose and Concrete Placement Hose Type: HN85

Concrete Pump Hose and Concrete Placement Hose

Concrete pump hoses and concrete placement hoses are designed with better durability due to the highly abrasion resistant inner tube. It offers more usage applications due to its excellent flexibility, as the hose is twist resistant during use, and supports reverse negative pressure during cleaning.

Advantages:

Application: This rubber hose is mainly used to transfer highly abrasive materials such as concrete slurry, sandblast slurry and more. It can also be used as the supply hose for concrete pump trucks, drilling rigs, pile drivers, and more.

Temperature Range: -30℃ ~ +100℃

Production Standard: EN 12001 / GB/T 27571

Construction:
  • Tube: Black highly abrasion resistant composite rubber with an excellent conductivity
  • Reinforcement: High strength steel cord
  • Cover: Black composite rubber that is abrasion resistant, aging resistant, and weather resistant
Concrete Pump Hose and Concrete Placement Hose
Technical Parameters:
Code No. Size (inch) I.D. (mm) O.D. (mm) W.P. B.P. MBR (mm) Weight (Kg/m) LengthMax (m)
(bar) (psi) (bar) (psi)
HN85-51 2 51 71 85 1275 200 3000 350 3.0 70
HN85-64 2.5 64 89 85 1275 200 3000 400 4.7 70
HN85-76 3 76 103 85 1275 200 3000 450 6.7 70
HN85-80 3.1 80 107 85 1275 200 3000 500 7.1 70
HN85-102 4 102 126 85 1275 200 3000 700 8.9 70
HN85-127 5 127 154 85 1275 200 3000 900 11.1 70
HN85-152 6 152 184 85 1275 200 3000 1000 15.1 70
