Offshore Bunker Supply Hose Type: SY10/SY20/SY40

Offshore Bunker Supply Hose

This heavy duty offshore bunker supply hose is applied in ports or wharfs to supply oil or fuel to water vessels. Nitrile rubber is used as the inner tube material and is covered with a composite of chloroprene and butadiene rubber material. This ensure resistance to sea water, oil, and gas.

Advantages:

Application: Offshore bunker supply hose is widely used for gasoline transportation, diesel, fuel containing up to 50% aromatic hydrocarbons, sea water, fresh water, slurry, air, etc.

Temperature Range: -30℃~ + 100℃

Construction:
  • Tube: Black nitrile rubber with excellent oil resistance, sea water resistance, thermal insulation, acid and alkali resistance;
  • Reinforcement: High strength composite fiber cord and conductive copper wire;
  • Cover: Black composite rubber made with chloroprene and butadiene rubber, providing abrasive resistance, ozone resistance, oil and thermal resistance and anti-aging performance, etc.
Offshore Bunker Supply Hose
SY10 Series Technical Parameters:
I.D. (inch) (mm)  O.D. (inch) (mm)  W.P. (bar) (psi)  B.P. (bar) (psi)  Safety Factor MBR (mm)  Weight (Kg/m)  Max. Length (m)
3/4 19 1.22 31 10 150 40 600 4 110 0.7 100
1 25 1.54 39 10 150 40 600 4 150 1.0 100
1-1/4 32 1.85 46 10 150 40 600 4 200 1.3 100
1-1/2 38 2.09 53 10 150 40 600 4 250 1.4 100
2 51 2.64 67 10 150 40 600 4 350 1.8 100
2-1/2 64 3.11 79 10 150 40 600 4 420 2.2 100
3 76 3.62 92 10 150 40 600 4 500 2.5 100
4 102 4.69 119 10 150 40 600 4 650 3.6 100
5 127 5.75 146 10 150 40 600 4 800 5.7 100
6 152 6.77 172 10 150 40 600 4 950 7.1 100
8 203 9.02 229 10 150 40 600 4 1400 11.3 100
SY20 Series Technical Parameters:
I.D. (inch) (mm)  O.D. (inch) (mm)  W.P. (bar) (psi)  B.P. (bar) (psi)  Safety Factor  MBR (mm)  Weight (Kg/m)  Max. Length (m)
3/4 19 1.22 31 20 300 80 1200 4 110 0.7 100
1 25 1.54 39 20 300 80 1200 4 150 1.0 100
1-1/4 32 1.85 46 20 300 80 1200 4 200 1.3 100
1-1/2 38 2.09 53 20 300 80 1200 4 250 1.4 100
2 51 2.64 67 20 300 80 1200 4 350 1.8 100
3 76 3.66 93 20 300 80 1200 4 500 2.8 100
4 102 4.84 123 20 300 80 1200 4 650 4.3 100
5 127 5.91 150 20 300 80 1200 4 800 6.8 100
6 152 6.93 175 20 300 80 1200 4 960 7.9 100
SY40 Series Technical Parameters:
I.D. (inch) (mm)  O.D. (inch) (mm)  W.P. (bar) (psi)  B.P. (bar) (psi)  Safety Factor MBR (mm)  Weight (Kg/m)  Max. Length (m)
3/4 19 1.22 33 40 600 160 2400 4 110 0.8 100
1 25 1.54 43 40 600 160 2400 4 150 1.2 100
1-1/4 32 1.85 50 40 600 160 2400 4 200 1.4 100
1-1/2 38 2.09 57 40 600 160 2400 4 250 1.8 100
2 51 2.64 72 40 600 160 2400 4 350 2.4 100
2-1/2 64 3.11 85 40 600 160 2400 4 420 3.0 100
3 76 3.62 98 40 600 160 2400 4 500 3.5 100
